please come on in, and enjoy my photographic adventure
J5 & Tad's quest for autocross traction.

Like any good project you have to start with research.
what do you have and what do you want?

this unassuming chart unlocks the puzzle

little time with tire rack and kumhoUSA pdfs and I was armed for the next step.
Mr Eric Vaughn..

he is a real nice guy and a walking legend in my mind.
cause he is actually the real deal modern day 2009 "fastest Indian" and SCTA member
this is were the magic happens

drop off and pick up was a local deal for me
Eric is an easy going guy
if you want work done give him a call.
two weeks goes by and
Mr. Vaughn calls
"your wheels are done."

"hope youlike um big?" he says

Eric's work is outstanding.
Tig welds inside and out.
Looks like a machine did it.
But I assure you this is 100% True American Crafstmanship

Eric said "this wheel was over designed, its heavy but strong"

Ohhhh. Ohhh...
I could just stare at this pair all day
See less See more
1 - 20 of 40 Posts
next up was the test fit

I was sweating bullets hoping the numbers came out good
this is the EV modded rim in test fit

the pan hard rod keeps the axle in check within .020" side to side movement
even with a big boy rocking the back of the car side to side
just two buisness cards from the frame w/o spacers!!!

still feeling like a gambler....I may have a chance that this will work

well, the day came...

time to cut the frame and purchase the tires
cross my fingers and hope this ish fits!

new rubber is dead sexy
335/35/17 sitting next to a 285/40/17

Somehow I already want a bigger tire

usually I do my own fab work,
but since this is a pretty indepth mod with big penalties for mistakes
I enlisted local hot rod hero and wildman Unique of Sire Fabrication in Ingelwood Ca 310.671.3430

Unique builds cars form scratch and has done this mod many times before.
His new twin SBC engine road race hot rod street car is beyond INSANE!

So we got to it and chopped the frame rail.
Miller plasma torch slices thru like butter.
Unique is smooth straight and steady.
I'm nervous and trying not to get in the way.

Insert burnout pic here..LOL

large amount of rubber dust was hiding in the rail from 10 years of burn outs and racing.
My car was still alive...
a new chapter called traction is just a turn of the page away
See less See more
weeks before the rims even showed up
I made a guesstimation of a template for the inner frame rail piece to be inserted.
The idea was to save some time during fabrication, since the old frame rail would not be re-used.

being a fan of over kill, i used THICK plate.
my degreed mechanical engineer friend and fellow racer insisted that
if the cross-sectional area was to be greatly reduced the gauge had to go up
in the event that the car was hit hard from behind it would be a shame if the car folded in half at the rear deck

also my car is showing signs of massive frame twisting on track
cracked the pan hard drop down brace twice
the windshield that cracked on course is heading for all four corners!!cwm5

extra strength is needed to resit the twist the panhard puts to the driver side rear frame rail
I really need a cage of some sort to tie the car together...
maybe later...

this picture is from the middle of the first day of the first event of last year
the crack has since grown
repeat after me: "the windshield is NOT a suspension component"

Unique fired up the Plasma and proceded to use up a couple of tips.
If you have ever used one of these things its hard to draw a realy nice arc,
Unique is just insanley good with this cutter

the thick plate fit right up inside the frame
no grinding was needed!!!
Unique then hammered and bent the frame to fit perfectly around / pinch the plate in place
*after this pic was taken

The plate was still warm from the plasma cutter when Unique fired up Mr Miller 212

Bitchen Phat welds ensued
Temp gun said 650F on the thick plate as Unique took a breather

no grinding needed
Just add paint and tire

See less See more
test drive was bitchen.
I could not get too crazy on Friday afternoon in downtown LA...

It all fits!
I could not be more happy.

We have landed! @ 335/35/17

special shout out and thanks to Mike Harris and DSSTRBD of the Impala Forum
for posting there pics in an earlier thread.
That inspiration and innovation drove me forward with this project!

if you have any questions about the pan hard rod for centering the axle
be sure to check out the link in my signature

thanks for tuning in
hope this help out the next guy :)
See less See more

Sire Custom Performance

423 E Florence Ave
Inglewood, CA 90301
(310) 671-3430

See less See more

Sire Custom Performance

423 E Florence Ave
Inglewood, CA 90301
(310) 671-3430

Holy Crap!! This car was in a photo shoot around the corner from my house a couple of days ago! That is truly a work of art!!

BTW, congrats on the frame work. It looks great with all that rubber out back!!
We have landed! @ 335/35/17
NICE! I'm still happy with the way my new 285/40/17's look in the back. 335's FTW
also my car is showing signs of massive frame twisting on track
cracked the pan hard drop down brace twice
Do you have the panhard bracket tied to the opposite frame rail? Maybe you have binding issues too.

Like any good project you have to start with research.
what do you have and what do you want?

this unassuming chart unlocks the puzzle
What, no Excel sheet... amateur.. :) This looks very similar to the design sheet I did when figuring out my home brew IRS and new wheels for my 53 F-100.

Nice work for sure on the frame mods. Your engineer friend exercises good judgement. I will be interested to hear if the extra tire is helping or hurting on the AutoX. A friend of mine went to split widths on his Camaro for AUtoX, and the car did not turn as well. THe car became less balanced,and understeered more on turn in, but he was able to get on the throttle earlier.
Dammmmmnn! That's freaking nice!
All that beautiful work, and you are running SPRING CLAMPS? WTF?! Get some springs made!
^^^After seeing how well Johnny 5 takes a corner, I think we should all be looking into getting spring clamps!:p
How much more did the wheels weigh?
I enjoyed reading your write up and photos.

These are the type of informative fun posts,
I have always enjoyed on the ISSF the last 9 years.

Thanks for sharing with everyone.
I like what you have done. Keep up the good work.

Nothing like old school Big Meats on a 208,500 mile daily driver 9c1,
that I have owned the last 11 years.

Goodyear 295-50-15" tires on the rear axle.
Junkyard 84 Chevy Suburban Rims for $40.00.

See less See more
I could not afford forgelines....:mad:
Yes, The rims are very heavy.
It's almost dumb.

Bottom line....They are 100% effective.
and I cant tell how heavy they are with a 3500+stall converter and 400+RWHP.


The spring clamps work great!!!
I hate picking springs.
HATE hate HATE changing springs that dont work.

Spring clamps allow for a change on the quick and cheap
and the results are predictable

if the car was lighter I would do this.

cause this is the right way to do it.
See less See more
Linked over from the wheel widening thread. Thanks for the write-up! I'd seen these details years ago, -hell that may have been you then too.
that is some serious business. nice job im sure the pics dont do those fattys justice. those are some serious x'ing tires
I have had some 335 35 17 Michelin Pilot sports on some 11" TTQ II's for a couple years. The only thing I did was to jack over the adjustable A arms to get equal clearence on both sides. I do run about 5-8 lbs in coil airbags if I carry 3 people with me. Not set up to to race like you did, just a street cruiser!


See less See more
I cant wait to do that
Can someone explain to me how that hot rod uses two motors?
